Thermopile Sensors are used for measuring non-contact surface temperatures. The ZTP-101T type is made up of thermo-elements, a flat Infrared (IR) filter, a thermistor for temperature correction, and a hermetically sealed small-size package. There are also other filters available to optimize performance in specific applications.
Applications
- Patient observation
- Tympanic and ear thermometers
- HVAC
- Appliances
- Occupancy detection
Features
- Fast response time
- High sensitivity
- Included ambient temperature (thermistor) sensor for compensation
- Low cost
- Non-contact measurement
- Small-size sensor package
- Wider surface area measurement
Specifications
Thermopile Chip
Source: Amphenol Advanced Sensors
| Parameter |
Limit Min |
Limit Typ |
Limit Max |
Units |
Conditions |
| Chip Size |
|
3.0 X 3.0 |
|
mm2 |
|
| Diaphragm Size |
|
1.5 x 1.5 |
|
mm2 |
|
| Active Area |
|
0.51 x 0.51 |
|
mm2 |
|
| Internal Resistance |
140 |
200 |
260 |
kΩ |
25 °C |
| Resistance T.C |
|
|
0.10 |
%/°C |
|
| Responsivity |
77 |
110 |
143 |
V/W |
500 K, 1 Hz |
| Responsivity T.C |
|
-0.11 |
|
%/°C |
|
| Noise Voltage |
|
62 |
|
nV rms |
R.M.S., 25 °C |
| NEP |
|
0.60 |
|
nW/Hz½ |
500 K, 1 Hz |
| Detectivity |
|
9.00 E07 |
|
cmHz½/W |
500 K, 1 Hz |
| Time Constant |
|
22 |
|
ms |
|
