MSR-Electronic Installs CO2 Gas Warning System for Gin Distillery Near Graz

MSR gas sensors detect hazardous ambient air during the production process.

Aeijst (pronounced A-st) is a Styrian gin. Named after the dialect word for branches. Produced in southern Styria. Aeijst is made from 100 % organic ingredients. 9 different botanicals such as juniper berries, lavender, ginger and coriander were first tasted individually, then combined in a harmonious recipe. Handcrafted out of honest conviction. Balanced in taste. Puristic, but not simple.

Copyright: Aejst Gin Distillery

For a certainly gentle and sustainable extraction of the various botanicals, the supercritical CO₂ extraction process has proven to be particularly efficient. Roughly translated, CO₂ extraction means the act of pulling certain substances out from a raw material by means of carbon dioxide. CO₂ is used as a solvent in this process where CO₂ is pressurised to over 73 bar and heated to approx. 30 °C. This process is also used, for example, for perfume, caffeine or cannabis production.

Gas alarm systems protect people whose workspaces are in danger zones. At the Aeijst gin distillery, the CO₂ gas detectors were renewed and brought up to date.

MSR solutions for the gas monitoring

Copyright: MSR-electronic, CO_2-gas alarm system Multi-Gas-Controller MGC2

The Multi-Gas-Controller (MGC2) from MSR-Electronic monitors toxic and combustible gases, refrigerants and oxygen in conjunction with gas sensors. In the Aeijst gin distillery, it is CO₂ that is measured. The MGC2 monitors the measured values and activates the alarm relays if the set alarm thresholds for pre-alarm and main alert are exceeded in case of gas leakage. Various output and input options allow for easy integration into existing systems. Up to 3 remote analog sensors can be connected to the MGC2. The MGC2 thus represents the compact variant for analog sensors.

BENEFITS

• Internal function monitoring with integrated hardware watchdog
• Hardware and software according to SIL compliant development process
• Easy maintenance by replacing the sensor heads or via comfortable on-site calibration
• Modular technology (plug-in and exchangeable)
• Reverse polarity protected, overload and short-circuit proof
• 3 analog inputs 4–20 mA for analog sensors
• 3 relays with change-over contacts, potential-free max. 240 V AC, 5 A
• 2 transistor outputs, 24 V DC, 0.1 A (plus switching)
• 2 digital inputs
• Serial RS-485 interface with protocol for DGC-06 or Modbus
• Different types of housing with IP65

Options

• Warning buzzer and status LED (WAO) for alarm, fault, operation and service
• Reset button, display, UPS
• Operating voltage 230 V AC with wide range input 100–240 V AC

Further information on MSR products can be found here in the current MSR-Electronic online catalog or in the webshop: www.msr-24.com.

The entire support and installation of the gas warning system was handled by the MSR branch,
MSR-Austria, www.msr-austria.at.

MSR-Electronic is a manufacturer of fixed gas warning systems with decades of experience in the field of building automation and gas measurement technology. The international company with headquarters in Germany has a wide range of methods for the detection of toxic and combustible gases. On this basis MSR-Electronic develops individual gas sensors, controllers and warning devices for many applications, such as parking garages, tunnels, petrochemical industry or shipping. The products meet more than the general standards and regulations and can therefore guarantee the safety of the plant. https://www.msr-electronic.de/en/
