Rohde & Schwarz introduces improved performance for phase noise analysis and voltage-controlled oscillator (VCO) measurements. Both the high end R&S FSWP phase noise analyzer and VCO tester plus signal and spectrum analyzer in one instrument, and the R&S FSPN dedicated phase noise analyzer and VCO tester, are now upgraded.
The upgraded R&S FSWP and R&S FSPN phase noise analyzers with the latest Rohde & Schwarz standard design as well as improved performance. Image Credit: Rohde & Schwarz
Simultaneous hardware and software upgrades improve the market-leading performance even further, reducing noise levels and measurement times, and increasing accuracy. Both analyzers include test sequence recording functions (SCPI recorder), unique for this class of instrument.
The new hardware basis common to both phase noise analyzers includes upgraded DC sources with reduced noise levels, further enhancing market-leading sensitivity. Users will appreciate the improved capacitive screen featuring higher color intensity and better antiglare properties, making the display brighter and clearer in all working conditions. In addition, multi-touch features like zoom are supported by the updated user interface. For very low noise oscillators with the inherent noise largely thermal at wider offsets, any potential cross-spectral collapse is now suppressed. In particular for production use, higher measurement speed for VCO measurements will help reduce the cost of test. With the newly introduced SCPI command recorder Rohde & Schwarz implements for the first time a function with phase noise measurement equipment to record sequences of manual settings. Using the command recorder, engineers can create easily repeatable test sequences, including the necessary synchronization to operate correctly.
The updated R&S FSPN and R&S FSWP phase noise analyzers are now available from Rohde & Schwarz. For further information, go to: https://www.rohde-schwarz.com/_256174.html
