Flammable gas sensors scan the surrounding air for flammable gases. They are deployed to detect gas leaks in residential gas stoves and heaters, gas stations, oil refineries, and facilities that store or utilize dangerous gases. Research and development efforts in the industry are focused on improving the accuracy of these sensors to ensure reliable gas detection.
Image Credit: Anne Webber/Shutterstock.com
What Are Flammable Gas Sensors?
Flammable gas sensors are devices that detect the presence of flammable gases in the atmosphere. These sensors can detect a wide range of flammable gases, including methane, propane, butane, and hydrogen.
Flammable gas sensors work by measuring the concentration of the gas in the air and providing an output signal that can be used to trigger an alarm or control a ventilation system.
Applications of Flammable Gas Sensors
Flammable gas sensors are used in various applications, including the oil and gas industry, chemical manufacturing, and mining. In the oil and gas industry, flammable gas sensors are used to detect leaks in pipelines and equipment, to ensure the safe operation of drilling rigs and refineries, and to protect workers from potential hazards.
In chemical manufacturing, flammable gas sensors are used to detect leaks in storage tanks and process equipment, to ensure the safe operation of the plant, and to protect workers from potential hazards.
In mining, flammable gas sensors are used to detect methane in underground mines, to ensure the safe operation of the mine, and to protect workers from potential hazards.
Challenges Faced by Flammable Gas Sensors
Several factors can affect the working of flammable gas sensors and impact the output signals produced by these sensors. These unwanted deviations in the output signals can lead to false alarms and failure in detecting gas leaks.
Accuracy is one of the main challenges faced by flammable gas sensors. The accuracy of these sensors is affected by various factors such as temperature, humidity, and the presence of other gases in the atmosphere.
For instance, high temperature can cause the sensor to produce a higher output signal than it should, while high humidity can cause the opposite.
Additionally, other gases in the atmosphere can interfere with the sensor's ability to detect flammable gas.
Calibration and maintenance are also important factors that must be considered. Proper calibration is essential for ensuring that the output signals from the sensor are not higher or lower than they should be.
Regular maintenance is also important for ensuring the accuracy of the sensor. Dust and other contaminants can accumulate on the sensor's surface, reducing its sensitivity and selectivity.
Another challenge faced by flammable gas sensors is the aging of the sensor. Over time, the sensitivity and selectivity of the sensor decrease, leading to a loss of accuracy.
This is due to the degradation of the sensor's materials and components, as well as the accumulation of dust and other contaminants on the sensor's surface.
Image Credit: Albina Gavrilovic/Shutterstock.com
The sensitivity and selectivity of the sensor are affected by the type of gas being detected and the concentration of the gas in the atmosphere.
The lower the gas concentration in the atmosphere, the more sensitive the sensor must be to detect it. However, increasing the sensor's sensitivity can also increase the likelihood of false alarms.
Similarly, a sensor that is not selective enough can produce false alarms or fail to detect gas leaks due to the presence of other gases in the atmosphere.
Cost is also an inevitable consideration in the use of flammable gas sensors. Some sensors are expensive to purchase and maintain, which can be a barrier to their widespread adoption in certain industries. In addition, the sensors need to be replaced periodically, which can add to the cost.
Recent Developments in Flammable Gas Sensors
Recently, scientists have focused on improving the accuracy and reliability of flammable gas sensors. One of the main developments in this area is using nanomaterials in the sensors. These materials have a high surface area-to-volume ratio, which allows for greater sensitivity and selectivity of the sensor.
In addition, researchers are also developing sensors that can be integrated with other sensing technologies, such as optical, electrochemical, and acoustic sensors, to improve their accuracy.
A recent partnership between two of the pioneers in the sensor industry, Blackline Safety Corp. and NevadaNano, resulted in the successful production of portable and wearable gas sensing systems containing Molecular Property Spectrometer (MPS) flammable gas sensors.
MPS provides the most precise and thorough gas detection data to improve safety and productivity in the workplace. The innovative multi-gas detection system is a long-awaited development in flammable gas sensing.
Compared to conventional flammable gas sensors, MPS sensors can report 0-100% LEL (Lower Explosive Limit) for 18 of the most notable flammable gases with high accuracy on a standard factory calibration and without the need for field maintenance over time. This eliminates the need for recurring calibration and bump tests. These sensors are also naturally immune to drift and decay.
Integrated, real-time monitoring and in-built pressure, temperature, and humidity adjustment further improve the MPS's accuracy, guaranteeing concentration readings are accurate over a wide variety of environmental conditions and offering unmatched false alarm reduction.
Conclusion
Flammable gas sensors are essential tools for ensuring the safety of workers and the environment in various industries. However, these sensors face several challenges that can affect their accuracy and reliability.
Recent developments in this field, such as the use of nanomaterials and the integration of other sensing technologies, could help to address the challenges faced by these sensors.
These developments will continue to improve the accuracy and reliability of flammable gas sensors and improve safety in the workplace.
References and Further Reading
Bhati, V. S., Takhar, V., Raliya, R., Kumar, M., & Banerjee, R. (2022). Recent advances in g-C3N4 based gas sensors for the detection of toxic and flammable gases: a review. Nano Express, 3. doi.org/10.1088/2632-959X/ac477b
Blackline Safety and NevadaNano Reach Milestone in Deployment of Industry-First Sensors. (2022, May 6). Available at: https://www.uktech.news/technology_news/blackline-safety-and-nevadanano-reach-milestone-in-deployment-of-industry-first-sensors
Flammable Gas Sensors: Which is the Best? (2021, February 19). Available at: https://gaslab.com/blogs/articles/flammable-gas-sensors-which-is-the-best
Kong, Y., Li, Y., Cui, X., Su, L., Ma, D., Lai, T., . . . Wang, Y. (2021). SnO2 nanostructured materials used as gas sensors for the detection of hazardous and flammable gases: a review. Nano Materials Science. doi.org/10.1016/j.nanoms.2021.05.006
