By Ankit SinghReviewed by Susha Cheriyedath, M.Sc.Jul 9 2024
Hydrogel sensors have emerged as a new, transformative technology across diverse fields due to their distinctive properties and wide-ranging applications. These sensors, primarily containing hydrophilic polymer networks that can retain substantial quantities of water, have garnered significant interest for their potential utility in biomedical, environmental, and industrial domains.
![What are Hydrogel Sensors?](https://d10lvax23vl53t.cloudfront.net/images/Article_Images/ImageForArticle_3077_17205457673585560.jpg)
Image Credit: masa44/Shutterstock.com
From Contact Lenses to Cutting-Edge Sensors
Hydrogels were first introduced in the 1960s as soft contact lenses, showcasing their biocompatibility and high water content. Over the decades, the development of hydrogels evolved significantly, expanding into various applications beyond ophthalmology. The introduction of hydrogel sensors marked a significant milestone in the evolution of these materials, driven by the demand for more sensitive, adaptable, and biocompatible sensing technologies.1
How Hydrogel Sensors Work: The Science Behind the Innovation
The fundamental principle underlying hydrogel sensors is their ability to undergo physical and chemical transformations in response to various environmental stimuli, such as changes in pH, temperature, glucose levels, and the presence of specific ions or molecules. These alterations in the hydrogel's properties, including swelling, transparency, and electrical conductivity, can be measured and leveraged to detect the presence and concentration of the environmental factors being monitored.2
How Are Hydrogels Shaping the Future of Biomedicine?
Transduction Mechanisms for Hydrogel Sensors
The integration of hydrogels with various transduction mechanisms, including optical, electrochemical, and mechanical systems, enables the development of highly sensitive and specific sensors.
Swelling and Responsiveness
One of the principal operating mechanisms of hydrogel sensors is volume expansion. These polymeric materials can imbibe substantial quantities of water, leading to significant increases in their size and dimensions. This hydrogel swelling can be triggered by a range of environmental factors, such as shifts in pH, temperature fluctuations, and the introduction of specific ions or biomolecules. By precisely quantifying the degree of volume change, researchers can correlate it with the concentration of the target analyte, enabling a sensitive and selective sensing approach.3
Electrical Conductivity Changes
Hydrogel sensors can also function based on changes in their electrical conductivity. The ionic conductivity of hydrogels can be modified in response to specific stimuli, such as changes in pH or the presence of ions. This alteration in conductivity can be detected and measured using electrochemical methods, enabling the quantitative analysis of the analyte concentration. This principle is particularly advantageous for developing sensors capable of detecting ions and biomolecules in diverse environments.3
Optical Transduction
Hydrogels can alter their optical properties in response to environmental changes. For instance, some hydrogels change their refractive index or transparency when exposed to specific stimuli. These alterations can be identified using optical techniques like spectroscopy or interferometry, offering a non-intrusive and extremely sensitive method of sensing. Optical hydrogel sensors are especially useful in biomedical scenarios where non-invasive monitoring is essential.3
Application of Hydrogel Sensors
Hydrogel sensors have revolutionized numerous industries with their unique properties and adaptable functionalities. This section explores the diverse applications of hydrogel sensors, highlighting their versatility and innovative contributions across various fields.
Glucose Monitoring in Diabetes Management
Hydrogel sensors have shown immense potential in the biomedical field, particularly in wearable and implantable devices. A recent article published in Advanced Healthcare Materials reported the development of a fluorescence-based glucose sensor using hydrogel for ongoing tracking in individuals with diabetes. The sensor showed great sensitivity and accuracy, providing a non-intrusive option to the conventional blood glucose monitoring techniques.4
Wound Healing Monitoring
Hydrogel-based sensors are emerging as effective tools for monitoring the wound healing process. These sensors can detect fluctuations in pH, temperature, and the presence of infection-related markers, offering valuable insights into the wound environment. This data can assist healthcare professionals in assessing healing progress and informing treatment decisions accordingly.5
The biocompatible and flexible nature of hydrogels makes them well-suited for wound monitoring purposes. They can be tailored to stick to the wound area without causing any irritation, and their ability to react to changes enables them to offer immediate updates on the condition of the wound. This innovation shows potential for enhancing patient results by facilitating more accurate and timely interventions in wound management.5
Targeted Drug Delivery
Hydrogel sensors are also being integrated into drug delivery systems to provide controlled and targeted release of medications. A recent ACS review highlighted the development of hydrogel sensors that react to specific biomarkers, releasing the drug only when necessary. This smart drug delivery system can enhance treatment efficacy and reduce side effects.6
These systems utilize hydrogels that change their properties in response to specific biological signals, such as pH or the presence of certain enzymes. This triggers the release of the drug at the target site, ensuring precise delivery and minimizing exposure to healthy tissues. This approach can improve patient outcomes by providing more effective and personalized treatment options.6
Tissue Engineering and Regenerative Medicine
In tissue engineering, hydrogel sensors are used to monitor the microenvironment and ensure optimal conditions for cell growth and tissue regeneration. A recent Sensors article demonstrated the use of hydrogel sensors to monitor pH and oxygen levels in real time, providing critical information for maintaining the viability of engineered tissues. This technology holds promise for advancing regenerative medicine and improving patient outcomes.7
These sensors can also be integrated into tissue scaffolds or culture systems, providing continuous feedback on the conditions within the engineered tissue. This information can be used to optimize the culture conditions and ensure that the tissue develops properly, enhancing the success of tissue engineering applications.7
Pesticide Detection in Agriculture
Hydrogel sensors are being used to monitor pesticide levels in agricultural fields. These sensors can identify even the smallest traces of pesticides, offering crucial information to farmers regarding the existence of harmful chemicals in their crops. This technology can help ensure food safety and promote sustainable agricultural practices.8
The sensors work by incorporating specific recognition elements that bind to pesticide molecules, causing a detectable change in the hydrogel’s properties. This facilitates rapid and precise pesticide detection, allowing for immediate interventions to prevent contamination and safeguard both human health and the environment.8
Force and Pressure Sensing
Hydrogel sensors are also being used to develop force and pressure sensors for soft robotics. These sensors can measure the force exerted by the robot on an object, providing valuable feedback for controlling the robot's movements. This capability is essential for tasks that require precise force application, such as gripping fragile objects or performing delicate manipulations.9
The ability to accurately measure force and pressure using hydrogel sensors enhances the functionality and versatility of soft robots. This technology can lead to the development of more advanced robotic systems that can perform a wider range of tasks with greater precision and reliability.9
Practical Challenges
Despite their promising applications, hydrogel sensors encounter several technical obstacles that need to be overcome. One of the main issues is enhancing their stability and resilience, especially in harsh environments. Hydrogels are naturally soft and vulnerable to deterioration, which can restrict their longevity and dependability in specific applications. Creating sturdier hydrogel materials and protective coatings can help overcome these challenges and increase the operational life of the sensors.
Another obstacle involves improving the sensitivity and selectivity of hydrogel sensors. While hydrogels can react to a wide array of stimuli, achieving high specificity for particular substances can be challenging. Advances in material design and functionalization, such as incorporating molecular recognition elements, can improve the selectivity of hydrogel sensors and expand their applications.
Integrating hydrogel sensors with electronic systems can also create difficulties. The high water content of hydrogels can disrupt electronic components, resulting in signal degradation and decreased performance. Developing compatible electronic interfaces and hybrid materials that combine the advantages of hydrogels and electronic systems can address this issue.
Future Prospects and Conclusion
The future of hydrogel appears promising, as current research is focused on improving its sensitivity, specificity, and longevity. Progress in material science and nanotechnology is set to advance the development of hydrogel sensors with better performance and new capabilities. Combining hydrogel sensors with sophisticated data analysis and artificial intelligence can further boost their usefulness, enabling more precise and real-time monitoring.
In conclusion, hydrogel sensors are a versatile and groundbreaking technology with substantial potential in various fields. From medical uses to environmental surveillance and flexible robotics, these sensors offer distinct advantages because of their adaptability, compatibility with living tissue, and responsiveness to environmental changes. As research and development continue to progress, hydrogel sensors will play a pivotal role in addressing some of the most urgent challenges in health, safety, and technology.
References and Further Reading
- Ho, T.-C. et al. (2022). Hydrogels: Properties and Applications in Biomedicine. Molecules, 27 (9), 2902. DOI: 10.3390/molecules27092902
- Pinelli, F.; Magagnin, L.; Rossi, F. (2020). Progress in hydrogels for sensing applications: a review. Mater. Today Chem, 17, 100317. DOI: 10.1016/j.mtchem.2020.100317
- Sun, X.; Agate, S.; Salem, K. S.; Lucia, L.; Pal, L. (2020). Hydrogel-Based Sensor Networks: Compositions, Properties, and Applications—A Review. ACS Appl. Bio Mater. DOI: 10.1021/acsabm.0c01011
- Sawayama, J.; Takeuchi, S. (2020). Long‐Term Continuous Glucose Monitoring Using a Fluorescence‐Based Biocompatible Hydrogel Glucose Sensor. Adv. Healthc. Mater, 2001286. DOI: 10.1002/adhm.202001286
- Zheng, K. et al. (2021). Flexible Bicolorimetric Polyacrylamide/Chitosan Hydrogels for Smart Real‐Time Monitoring and Promotion of Wound Healing. Adv. Funct. Mater, 31 (34), 2102599. DOI: 10.1002/adfm.202102599
- Sonker, M. et al. (2021). Review of Recent Advances and Their Improvement in the Effectiveness of Hydrogel-Based Targeted Drug Delivery: A Hope for Treating Cancer. ACS Appl. Bio Mater, 4 (12), 8080–8109. DOI: 10.1021/acsabm.1c00857
- Fedi, A.; Vitale, C.; Giannoni, P.; Caluori, G.; Marrella, A. (2022). Biosensors to Monitor Cell Activity in 3D Hydrogel-Based Tissue Models. Sensors, 22 (4), 1517. DOI: 10.3390/s22041517
- Jin, R. et al. (2021). Construction of multienzyme-hydrogel sensor with smartphone detector for on-site monitoring of organophosphorus pesticide. Sens. Actuators B, 327, 128922. DOI: 10.1016/j.snb.2020.128922
- Hegde, C. et al. (2023). Sensing in Soft Robotics. ACS Nano. DOI: 10.1021/acsnano.3c04089
